SPS-Cl Chlorine Water Quality Sensor

The chlorine sensor adopts membrane-covered, amperometric potentiostatic 3-electrode, which effectively improves the sensor’s measurement stability and accuracy. The free chlorine or total chlorine factor enters the sensor through the selective permeability membrane, and a redox reaction occurs on the surface of the gold electrode to generate a weak current. The signal value obtained after processing is proportional to the free chlorine or total chlorine concentration. After calculation, the free or total chlorine concentration can be obtained. SPS-Cl series chlorine sensors are widely used in tap water, pipe networks, medical sewage, and other fields and can provide customers with accurate and efficient monitoring.

Parameter: Free Chlorine, Total Chlorine, Residual Chlorine, Temperature

Three-electrode coating method, stable and accurate measurement
No chemical reagent consumption, environmentally friendly
Long maintenance-free period and low maintenance cost
The device is compact and easy to install

Specification

Item	Specification
Principle	Membrane covered, amperometric potentiostatic 3-electrode
Dimension	φ25×205mm
Power requirements	DC+12V~+24V
Operating temperature	2 to 45℃
Pressure	1 bar
Installation	Submerged, Flow-through
Sample flow rate	200-500mL/min
Communication	RS485(Modbus RTU)

Parameter

Parameter	Model No.	Range	Resolution	Accuracy （Standard solution）
Free Chlorine	SPS-Cl-F	0-2 mg/L, 0-5 mg/L, 0-20 mg/L	0.001 mg/L	±3% F.S.
Total Chlorine	SPS-Cl-T	0-2 mg/L, 0-5 mg/L, 0-20 mg/L	0.001 mg/L	±3% F.S.
Temperature	SPS-Cl	2-50 °C	0.1 °C	±1 °C
